Type

FTTx Solutions

No. of Fiber

1.

Use

FTTH

Applicable fibers

SM(G.652/657), MM(G.651), DS(G.653), NZDS(G.655)

Fiber count

single fiber

Splicing loss

0.03dB(SM).0.03dB(MM),0.04dB(DS/NZDS)

Typical splice loss

0.05dB (SM), 0.02dB(MM), 0.08dB(DS) and 0.08dB(NZDS)

Return loss

>>60dB

Typical splice time

9 seconds

Typical tube heating time

24 seconds

Outter Diameter

158(L)*130(W)*156H)mm

weight

2.14KG(with battery )

Tension test

2N
